F Class Dmd Electrical Insulation Paper
DMD is a three-layers flexible composite material. --First layer: polyester non-woven fabric cloth. --Second Layer: Polyester film(PET). --Third Layer:.
Description
DMD is a three-layers flexible composite material. --First layer: polyester non-woven fabric cloth. --Second Layer: Polyester film(PET). --Third Layer: polyester non-woven fabric cloth. It has high dielectric properties, tear strength and tensile strength, good impregnation performance The insulation materials products have been approved by UL (NO.: E310670) ,ROHS and RECH test.
Technical Specifications
|
Properties |
Units |
Values |
|||||||||
|
Nominal thickness |
mm |
0.15 |
0.17 |
0.20 |
0.23 |
0.25 |
0.30 |
0.35 |
|||
|
Thickness tolerance |
mm |
±0.02 |
±0.03 |
±0.04 |
|||||||
|
Grammage and tolerance |
g/m2 |
180±25 |
210±30 |
240±30 |
260±35 |
300±40 |
350±50 |
430±50 |
|||
|
Tensile strength |
MD |
No bending |
N/10mm |
≥80 |
≥120 |
≥140 |
≥180 |
≥190 |
≥270 |
≥320 |
|
|
After bending |
≥80 |
≥105 |
≥120 |
≥150 |
≥170 |
≥200 |
≥300 |
||||
|
TD |
No bending |
≥80 |
≥105 |
≥120 |
≥150 |
≥170 |
≥200 |
≥300 |
|||
|
After bending |
≥70 |
≥90 |
≥100 |
≥120 |
≥130 |
≥150 |
≥200 |
||||
|
Elongation |
MD |
No bending |
% |
≥15 |
/ |
||||||
|
After bending |
≥10 |
≥5 |
|||||||||
|
TD |
No bending |
≥20 |
/ |
||||||||
|
After bending |
≥10 |
≥5 |
|||||||||
|
Breakdown Voltage No bending |
KV |
≥6 |
≥7 |
≥9 |
≥10 |
≥12 |
≥15 |
≥18 |
|||
|
Bonding property at room temp. |
/ |
No delamination |
|||||||||
|
Bonding property at 180±2℃ 10min |
/ |
No delamination, no bubble, no adhesive flow |
|||||||||
|
Temp. index of heat-resistance in a long term (TI) |
/ |
≥155 |
|||||||||
|
The quality warranty period |
Twelve months |
||||||||||
